SPECIFICATIONS:

RATED CAPACITY: 60,000LBS

RAIL WIDTH: 36″

WINCH TYPE: REECVING HYDRAULIC CYCLINDERS

HOIST LENGTH: 23.3 FT

DUMP ANGLE: 48 DEGREES

OPERATING PRESSURE: 2,500 PSI

STRUCTURAL COMPONENTS

•  HEAVY DUTY 10″ X 4 X 3/8″ MAIN FRAME TUBE
• HEAVY DUTY 4″ X 4″ X 3/8″ SUBFRAME
• DUAL OUTBOARD LIFT CYLINDERS
• DUAL CABLE REEVING CLYLINDERS
•  2 1/2″ DIAMETER REAR HINGE PINS
•  PINTLE HITCH READY APRON
• ADJUSTABLE DOT BUMPER FOR PUP TRAILERS
•  3″ DIAMETER LIFT CYLINDER SHAFTS
• 3/8 INCH X 5-INCH WINCH CYLINDER ROD COVERS
•  6 INBOARD AND OUTBOARD REINFORCEMENT CAGE FOR OUTSIDE ROLLERS
•  HEAVY DUTY CONTAINER LONG SILL SUPPORTS ON REAR OF HOIST MAINFRAME 48″ x 3/4″ x 4″ x 4″
•  48 GALLON HYDRAULIC OIL RESERVOIR WITH SIGHT GLASS, FILTER ELEMENT & TEMPERATURE GAUGE

SAFETY ENHANCEMENTS

• HOIST UP ALARM
• HOIST UP BODY LIGHT WITH BODY SWITCH SENSOR
• BACK UP ALARM
• LED WORK LIGHTS
• AUTOMATIC AIR BAGS DEFLATION SYSTEM CONNECTED TO PTO SWITCH FOR (AIR RIDE CHASSIS)

OPERATOR CONTROLS

• ALUMINUM ENCLOSED AIR CAB JOYSTICK CONTROLS WITH PTO SWITCH, LED LIGHTS SWITCH
• 5 SPOOL OUTSIDE HOIST VALVE CONTROL
