AMERICAN MADE. AMERICAN TOUGH.
Bob Unilift TL 60000, maintains the same foot print with minimal weight increase compared to its smaller brother the TL 50000 while achieving an additional 10,000lbs of lift capacity.
FEATURES
MODEL: TL 60000 NL
RATED CAPACITY: 60,000 LBS
HOOK HEIGHT: 54″62″
CONTAINER LENGTHS: 18-24 FT
DUMP ANGLE: 46°
WEIGHT: 6,261 LBS
OPERATING PRESSURE: 4,600 PSI
OIL TANK US GALLLONS: 42
HOOK HEIGHT
HOOK HEIGHT: 54″62″
OPTIMAL BODY LENGTHS
18-24 FT
TARP SYSTEMS
AMERICAN TARP
MODEL: X
CHASSIS REQUIREMENTS
CHASSIS CA/CT REQUIREMENTS: 205/217
AXLES: SINGLE
MINIMUM GVWR: 64,000
